20hp Piston Compressor Commercial Cold Storage Application 4GE-23(4G-20.2)

Model Number : 4GE-23

Certification : CE, ROHS

Place of Origin : CHina

MOQ : 1

Price : discussed

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000

Delivery Time : 1-7DAYS

Packaging Details : wooden packaging

Voltage : 380v-420v /3 Ph / 50Hz

Brand Name : ( 20hp commercial

Weight : 192kgs

Configuration : Stationary

Horsepower : 20HP

Oil : Mineral oil / Polyester Oil

Power Source : AC Power

Contact Now



1. We are first level agent for offering you competitive price.



2. We have all Models available.



3. We prodive fast delivery within 1-7 days after payment.



4. We provide perfect after sales service.



5. We have regular clients of product from both home and abroad.



1) New valve plate design

  • New geometric concept for pressure valves – for low rear expansion.
  • High cooling capacity with minimal energy requirements.
  • The ECOLINE cylinder head system: Flexible operation in tandem.

2) Motor

  • Efficient under full- and part-load thanks to its broadband characteristics.
  • The universal refrigeration compressor: Motor version 2 for medium and low temperature applications.
  • Motor versions 1 and 3 for special applications.

3) Capacity control

  • The CRII system – intermittent blocked suction For example, 4-cylinder compressor with CRII on both heads: Range of control from 100% to ~10%
  • ECOLINE VARISPEED – built-in frequency inverter

4) Downward compatible

  • Essential internal components completely redesigned.
  • Outer contour as standard: Every ECOLINE is downward compatible
5) Drive gear
  • New piston and connecting rod design
  •   SI IP
    Displacement (1450 RPM 50Hz) 84,5 m³/h 2984.1 CFH
    Displacement (1750 RPM 60Hz) 101,98 m³/h 3601.4 CFH
    No. of cylinder x bore x stroke 4 x 75 mm x 55 mm 4 x 2.95 inch x 2.17 inch
    Weight 192 kg 423 lb
    Max. pressure (LP/HP) 19 / 32 bar 275 / 464 psi
    Connection suction line 54 mm - 2 1/8'' 54 mm - 2 1/8''
    Connection discharge line 28 mm - 1 1/8'' 28 mm - 1 1/8''
    Oil type R134a/R407C/R404A/R507A/R407A/R407F BSE32(Standard) / R134a tc>70°C: BSE55 (Option) BSE32(Standard) / R134a tc>155°F: BSE55 (Option)
    Oil type R22 (R12/R502) B5.2(Option) B5.2(Option)





    Extent of delivery(Standard) of 20hp commercial cold storage compressor 4GE-23

    (4G-20.2)

      SI IP
    Motor protection SE-B2 SE-B2
    Enclosure class IP54 (Standard), IP66 (Option) IP54 (Standard), IP66 (Option)
    Vibration dampers Standard Standard
    Oil charge 4,50 dm³ 158.4 fl oz





    Motor Data of 20hp commercial cold storage compressor 4GE-23(4G-20.2)

      SI IP
    Motor version 2 2
    Motor voltage (more on request) 380-420V PW-3-50Hz 440-480V Y-3-60Hz UL
    Max operating current 43.9 A 43.9 A
    Winding ratio 50/50 50/50
    Starting current (Rotor locked) 97.0 A Y / 158.0 A YY 176.0 A





    Sound Measurement of 20hp commercial cold storage compressor 4GE-23(4G-20.2)

      SI IP
    Sound power level (-10°C / 45°C) 81,0 dB(A) @50Hz 83,5 dB(A) @60Hz
    Sound power level (-35°C / 40°C) 86,5 dB(A) @50Hz 89 dB(A) @60Hz
    Sound pressure level @ 1m (-10°C / 45°C) 73 dB(A) @50Hz 75,5 dB(A) @60Hz
    Sound pressure level @ 1m (-35°C / 40°C) 78,5 dB(A) @50Hz 80,5 dB(A) @60Hz
    Sound power level (-10°C / 45°C) R134a 79 dB(A) @50Hz 81,5 dB(A) @60Hz
    Sound pressure level @ 1m (-10°C / 45°C) R134a 71 dB(A) @50Hz 73,5 dB(A) @60Hz





    20hp Piston Compressor Commercial Cold Storage Application 4GE-23(4G-20.2)

    20hp Piston Compressor Commercial Cold Storage Application 4GE-23(4G-20.2)
